If you spend any decent amount of time in the kitchen, then you’ll agree that it’s super annoying when cabinet doors won’t close or line up. It’s also frustrating when cabinet doors are crooked, won’t stay closed, or bang into the wall/ kitchen door whenever you open drawers.
Most kitchen cabinets from the last couple of decades, including our Kraftmaid inventory, feature European-style concealed hinges. Thanks to their three built-in adjustment screws, you can easily fix alignment issues with a Philips screw driver, i.e., a door that’s sagging, sticking out, or refusing to latch.
Let’s walk through how to adjust cabinet hinges step by step. By the end, you’ll know how to align cabinet doors like a pro, and you won’t need to call in help or spend a dime on parts.
Types of Cabinet Hinges You Might Have
Let’s start with a quick look at the type of hinges you’ve got so we can tell how it affects the fix.
1. European (Concealed) Hinges
These are the round, cup-shaped hinges hidden inside the cabinet. You can only see them by opening the door, and they’re standard on most kitchens built in the last 20+ years. Again, they’re popular thanks to the three built-in screws that fix alignment issues.
2. Soft-Close Hinges
These are similar to European hinges but feature a small built-in damper for slowing down the door before bangs shut. It also has the same adjustment screws and process, though the damper demands special adjustments as well.
3. Face-Frame vs. Frameless Hinges
We also have face-frame vs. frameless hinges, but let’s not explore these now, unless you’re interested in reversing cabinet doors.
The Tools You’ll Need to Adjust Kitchen Cabinet Door Hinges
You likely already have everything you need for the job.
The Essentials
A Phillips head screwdriver is really all it takes, the standard size.
Nice to Have (But Not Required)
A flashlight comes in handy if your cabinets are dark inside or up high. You may also need a rag for wiping away dust or grime around the hinge before you start turning screws. Both aren’t essential, but they make the job a little easier.
How to Adjust European Cabinet Hinges
Again, these hinges feature three screws, and each one controls a different direction. Learn these three to fix almost any door problem.
Screw 1: Depth Adjustment
This screw regulates how far in or out the door sits from the cabinet frame. Turning it clockwise pulls the door inward, while turning it anticlockwise pushes it outward.
Tune it when a door sticks out too far or sits deeper than adjacent doors.
Screw 2: Height Adjustment
This screw is usually on the mounting plate and moves the door up and down. Gravity keeps tagging open cabinet doors downwards, you need to keep adjusting this screw more than the others.
Screw 3: Side-to-Side (Lateral) Adjustment
This screw shifts the door left or right. Adjust it when the gap between two doors is uneven, or when a door overlaps its neighbor.
How to Make the Adjustment
- Turn each screw in small increments to avoid overcorrection and straining the door hinges.
- It may take a few tries to get the right balance between doors, and that’s okay.
- Check again after 24 hours and tighten if necessary.
- Work on one screw at a time to track the changes.
Fixing Specific Cabinet Door Problems
Here’s how to solve the most common complaints, using the three screws you just learned.
1. Cabinet Door Won’t Stay Closed
This complaint usually boils down to depth. Turn the depth screw clockwise to pull the door in a bit further, giving the latch enough contact to catch.
If the door still pops open, check the lateral screw too because a door that’s shifted slightly off-center seats awkwardly on the frame.
2. Doors Don’t Line Up With Each Other
Uneven gaps between two side-by-side doors are a lateral adjustment issue. Pick one door as your reference point, then adjust the other door’s lateral screw until the gap matches. Small quarter-turns work best here since even a slight shift changes the gap noticeably.
3. Door Sags or Hangs Crooked
Over time, the weight of the door can cause it to droop, especially on taller cabinets, but there’s a height screw on the mounting plate to fix this problem.
Turn it to raise the low side until the door sits level with the others. If the screw feels loose or spins without effect, the mounting hole may be stripped. In that case, stick around as we’ll address this complication in Section 7.
4. Door Hits the Frame or the Cabinet Next to It
This problem is more complex than the others we’ve discussed. It tells you that you must adjust for depth and lateral alignment.
Start with the depth screw to pull the door in, then fine-tune with the lateral screw to shift it away from the frame or adjacent cabinet.
Adjust one at a time and test after each turn so you can see which one is doing the work. On that note, here’s how to fix kitchen cabinets pulling away from wall.
How to Adjust Soft-Close Cabinet Hinges
Again, soft-close hinges are similar to European hinges, so the adjustment tips from earlier apply. However, these soft-close hinges feature a damper for slowing down the door as it closes.
This small, piston-like mechanism creates a few unique problems you don’t get with European hinges.
1. Door Doesn’t Fully Close
If your door doesn’t fully close, you probably have a depth problem.
Turn the depth screw clockwise to pull the door in slightly, giving the damper enough contact to finish the swing and let the door latch.
2. Door Slams Too Hard or Closes Too Slowly
Some soft-close hinges have a small dial or lever on the damper itself, separate from the three main screws, that adjusts how much resistance it applies. If yours has one, a small turn will speed up or slow down the close.
If yours doesn’t have this feature, adjust the depth screw.
3. Door Bounces Back Open
This annoyance occurs when you close the door too hard, and it rebounds off the damper. You may need to adjust the depth or lateral screws, or both, to fix this misalignment.
4. No Damper on the Hinge
Some cabinets feature the damper separately from the hinge, positioned near the top or bottom of the cabinet box.
If you don’t see a damper built into the hinge arm, look for a small block-shaped piece instead. You’ll have to adjust or reposition it separately from the hinge.
5. Adjusting the Cabinet Door Damper
To adjust the damper, first open the cabinet door fully and locate the small screw on the damper block or hinge arm. This screw controls how much resistance the damper provides when you open and close the door.
Using a Phillips head screwdriver, turn this screw clockwise to increase resistance or counterclockwise to decrease it. Experiment with different resistance levels until you find a setting that works best for your needs.
When Adjustment Isn’t Enough
Sometimes, adjustments won’t do because the hardware is damaged. Here’s how to tell.
1. Stripped Screw Holes
Years of use could strip out the mounting hole, causing the screw to spin freely without tightening. So, the door won’t hold its position no matter what.
Dip a toothpick or matchstick in the wood glue commonly used to fill chips in kitchen cabinets. Then insert it into the hole to improve the screw’s grip. If that fails, you can replace the mounting plates.
2. Cracked or Broken Hinge Cup
Check the round cup embedded in the door. Replace the hinge if it’s cracked or bent, or if the door still wobbles after you tighten the screws.
3. Worn-Out Soft-Close Damper
Remember how we described adjusting the hinge and damper to stop the soft-close door from slamming? If that fix keeps failing, the damper has likely worn out internally.
You can replace dampers individually without swapping the whole hinge.
When to Replace vs. Repair
A good rule of thumb is that you’re fine if the screws turn smoothly and the hinge holds its position once adjusted. If the hardware feels loose, damaged, or unresponsive to adjustment, it’s time to replace the hinges.
Preventive Tips: (Doors That Won’t Close or Line Up)
A few small habits go a long way toward keeping your cabinet doors adjusted and working right.
1. Check Screws Periodically
Cabinet hardware loosens naturally over time from the weight of the door and everyday use. A quick check every few months, especially on frequently used cabinets, catches small shifts before they turn into bigger problems.
2. Keep Hinge Tracks Clean
Dust and grime can build up around the hinge mechanism, especially in kitchens, and that buildup can affect how smoothly the door closes. Wipe down the hinge area occasionally to keep everything moving the way it should.
3 Don’t Over-Tighten
It’s tempting to crank a screw down hard if a door feels loose, but over-tightening can strip the particleboard behind the mounting plate, which creates the exact problem you’re trying to avoid.
A snug fit works just fine.
FAQ on Doors That Won’t Close or Line Up
1. How do I adjust kitchen cabinet doors that are uneven?
Use the lateral screw on the hinge to shift the door left or right until the gap matches the adjacent doors. If the doors are uneven top to bottom, adjust the height screw.
2. Why won’t my cabinet door stay closed?
It’s almost always a depth adjustment issue. Turning the depth screw clockwise pulls the door in far enough for the latch to catch.
3. How do I align cabinet doors that overlap wrong?
Adjust the lateral screw on the overlapping door until it sits flush with its neighbor. Small quarter-turns work best, since even a slight movement changes the overlap.
4. Can I adjust soft-close hinges myself?
Yes. Soft-close hinges use the same three adjustment screws as standard European hinges, so the process is identical. Some models also have a separate dial for damper speed, but that’s optional, and not every hinge has one.
Getting Your Cabinet Doors Back on Track
We’ve explored how you can easily adjust your misaligned cabinet doors with the three relevant screws. We also recommend exploring how to hang kitchen cabinets on plaster walls.
If you’ve worked through these adjustments and the hardware still isn’t cooperating, that’s usually a sign it’s time for new hinges rather than another round of turning screws.
